Name: ZAi-M15 Pro
Brand: HongKong Global Intelligence Technology Group Limited



+86-18818709844



aric@industrial-gradedrone.com





Key Highlights of ZAi-M15 Pro FPV Drones

8kg maximum heavy payload limit.

30 m/s maximum climb speed in Attitude mode

Extended flight time ≥60 minutes without payload

10–15 km ultra-far control distance

Multiple power supply outputs and rich expansion interfaces (CAN, UART, I2C, ADC, PWM)

Space-saving foldable design with 12 m/s wind resistance capability

High Agility, Long-Range 7-inch FPV Interceptor Drone

The ZAi-M15 Pro is a high-performance 13-inch FPV drone engineered for heavy-payload operations up to 8kg. Boosting mission capabilities with over 60 minutes of endurance, a 30 m/s ascent rate, and a 15km control range, its rich expansion interfaces make it an adaptable platform for custom setups.

Key Benefits of ZAi-M15 Pro FPV Drones

Heavy-Duty Payload

Carries up to 8kg, enabling heavy industrial equipment and tactical payload transportation with maximum operational efficiency.

Extreme Flight Endurance

Delivers over 60 minutes of uninterrupted flight time without payload, ensuring extended field missions and reliable performance.

Rapid Ascending Speed

Reaches an extraordinary climb speed of 30 m/s in Attitude mode for quick tactical deployments and fast elevation.

Ultra Long-Range Control

Maintains stable signal transmission up to 15km, offering expansive operational coverage for complex, long-distance missions.

High Hardware Expandability

Features versatile CAN, UART, and multi-voltage power interfaces for seamless integration with specialized custom hardware.

Foldable & Wind-Resistant

Combines a space-saving foldable design with 12 m/s wind resistance for easy transport and reliable flight stability.

Specification of ZAi-M15 Pro FPV Drones

Parameter	Value
Overall Unfolded Dimensions (incl. propellers)	864mm × 854mm × 145mm
Folded Dimensions	423mm × 253mm × 145mm
Diagonal Wheelbase	682mm
Standard Takeoff Weight	5.8kg
Maximum Payload Capacity	8kg
Maximum Climb Speed	Positioning mode: 8 m/s
	Positioning mode: 8 m/s
	Attitude mode: 30 m/s
Maximum Descent Speed	Positioning mode: 5 m/s
Maximum Flight Time	≥60 min (no payload)
	≥60 min (no payload)
	≥10 min (with 10kg payload)
Maximum RC Range	10-15km
Communication Frequency Band	Standard dual-band 2.4G/5.8G (customizable)
AI Recognition & Tracking	Supported
Expansion Interface	Power supply: 1×12V/3A, 1×5V/5A
	Power supply: 1×12V/3A, 1×5V/5A
	Interfaces: 1×CAN, 1×UART, 1×I2C, 1×ADC, 1×PWM
Wind Resistance	12 m/s

Technical Consultation & Project Requirements

Share your mission specifications—such as payload capacity, endurance needs, or environmental constraints. Our engineering team will review your data and provide a optimized UAV configuration tailored to your industrial workflow.
